Edge Banding Machine Supplier End Cutting Fine Trimming Time Efficiency

Edge Banding Machine Supplier End Cutting Fine Trimming Time Efficiency

Brand Name:	BH
Model Number:	BHM 368F
MOQ:	1
Price:	Negotiable
Payment Terms:	,T/T
Supply Ability:	3000Sets/Year

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao China

Certification:

Dimension:

3500*750*1500mm

Weight:

1000KG

Voltage:

380V/50Hz

Power:

7KW

Thickness:

10-60mm

Pressure:

0.7Mpa

Packaging Details:

3600*850*1600mm

Highlight:

7KW Automatic Edge Banding Machine

10-60mm Edge Banding Machine

0.3~3mm Woodworking Edge Banding Machine

Product Description

Edge Banding Machine Supplier End Cutting Fine Trimming Time Efficiency

Our edge banding machine delivers exceptional time efficiency with end cutting and fine trimming capabilities. We produce high-quality products with fast delivery and support complete customization including color, LOGO, engine, and air conditioning configurations. Custom orders available starting from just 1 piece.

Product Overview

The BHM START 300 automatic edge banding machine is ideal for board shops and small processing factories. It features vertical display control panels and hand-cranked digital display adjustment for pressure beam height. The machine's large-capacity glue pot enables continuous edge sealing, processing plates through gluing, pressing, trimming, and finishing in one seamless operation.

Technical Specifications

Specification	Value
Outline dimension	35007501500mm
Conveyor speed	18~24m/min
Machine weight	1000KG
Minimum width of board	50mm
Working voltage	380V/50Hz
Minimum length of board	70mm
Total power	7KW
Working pressure	0.7Mpa
Plate thickness	10-60mm
Edge banding thickness	0.3~3mm

Key Features

Encoder: Advanced encoder controls all machine functions with quick responsiveness and low failure rate
Intelligent Control: PLC-based microcomputer control system ensures operational stability and safety
Glue System: Heated glue tank with suction structure provides even adhesive application
End Cutting: Precise edge cutting with single guide rails at both ends
Fine Trimming: High-speed slanted cutting motor with durable alloy disc for smooth edges

Customer Benefits

Our woodworking machinery offers affordable, customizable solutions available in various models to perfectly meet your requirements, whether you need small or large-scale equipment.

Supplier Advantages

Our innovative woodworking machinery sets industry standards with durability and advanced features. We provide attractive profit margins, 1-3 years of after-sales service, and expedited air shipping for critical parts. All products undergo pre-delivery testing, and we offer free promotional support in your market.

Frequently Asked Questions

Q1: Can customized services be supported?

A1: Yes, we can customize the color, size and logo you need.

Q2: Where is your factory located?

A2: We are a Chinese manufacturer in Qingdao City, Shandong Province.

Q3: Can you make the machine according to my design or prototype?

A3: Yes. We have professional designers to create the most suitable design and production plan for your requirements.

Q4: Is this machine easy to operate for first-time users?

A4: We provide instructional videos and English manuals. Free professional guidance is available until you can operate the machine proficiently.

Q5: What's your MOQ and delivery terms?

A5: MOQ is 1 set. We ship directly to your country's port - please provide your port name for best shipping rates.

Q6: How is your after-sales service?

A6: Our sales team is available 24/7. We also offer overseas installation service.

Q7: What if my machine needs repair?

A7: We provide free online training. For major issues during warranty, we will repair the machine.

Shipping Information

The edge banding machine will be carefully packaged and shipped within 15-30 days of order confirmation. Delivery times may vary depending on your location and shipping method. Tracking details will be provided once the shipment is dispatched, and we ensure secure packaging to prevent damage during transit.
