| Brand Name: | BH |
| Model Number: | BHM-45D |
| MOQ: | 1 |
| Price: | 1300-1700USD |
| Payment Terms: | T/T |
| Supply Ability: | 3000sets/year |
| Specification | Value |
|---|---|
| Push table length | 3200 mm |
| Push table width | 375 mm |
| Motor power | 5.5 *1.1KW |
| Sawshaft speed | 4000-6000RMP |
| Speed of Scoring saw blade | 7000-8000RMP |
Cutting Capacity: Maximum cutting length of 3100 mm and thickness of 70 mm, with a versatile cutting angle range of 0–45°.
Worktable: Features a large sliding table (3200 × 375 mm) with a reinforced push table for smooth and stable material handling.
Motor System: Powered by a high-performance 5.5 kW main motor and a 1.1 kW scoring motor, ensuring clean, chip-free cuts. Both motors are mounted above the frame for improved durability and maintenance access.
Saw Blades: Equipped with a 300 mm main saw blade and a 120 mm scoring blade, running at 4000–6000 RPM and 7000–8000 RPM respectively for precise scoring and cutting.
Digital Control: Integrated digital display for accurate angle setting (0–90°) and electric lifting for quick and easy saw blade adjustment.
Enhanced Usability & Design
Intelligent Automation for Enhanced Productivity
The BHM-45S sets a new standard with its fully motorized blade elevation system (electric lifting), allowing for rapid, effortless height adjustments at the push of a button. This, combined with a precise digital angle display (0-90°), minimizes setup time, reduces operator fatigue, and ensures repeatable accuracy for batch production and complex angled cuts.
Unrivaled Structural Integrity
Built for a lifetime of heavy-duty service, its chassis features a massively reinforced framework with 6mm front/rear panels and a formidable 16mm thick top plate. This exceptional rigidity, coupled with a total weight of 750kg, guarantees vibration-free operation and enduring alignment, forming the perfect foundation for micron-level precision.
Performance-Driven Design
It is powered by a reliable 5.5kW main motor and a 1.1kW scoring motor for pristine, pre-scored cuts. The fine-tune rip fence glides on a solid 45mm chrome-plated shaft, while a heavy-duty crosscut fence (1850mm with dual flip stops) ensures versatility. An optimized ergonomic adjustment handle provides superior tactile feedback for fine-tuning.
Complete Workshop Solution
The saw includes a full-size workbench and a pressure feeder for safe handling of large panels. A dedicated 150mm dust extraction port with a moving saw hood maintains a clean and healthy work environment.
The Table Saw is widely used in:
Furniture manufacturing for panel sizing and cutting
Batch production of custom cabinets, wardrobes, and other furniture
Door, window, and decorative trim processing, including bevel cuts
Precision cutting of engineered wood panels such as particleboard, MDF, and plywood
Ideal for woodworking shops, building material processing workshops, and custom furniture production lines
