Wood Door Making CNC Router Machine Automatic Wood Carving CNC Router

Wood Door Making CNC Router Machine Automatic Wood Carving CNC Router

Brand Name:	BaiHang
Model Number:	BH2140S
MOQ:	1
Price:	$2400 - $3000
Payment Terms:	T/T
Supply Ability:	3000sets /year

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao ,China

Certification:

Document:

BHM1325M.pdf

Number Of Vacuum Zones:

Place Of Origin:

Shandong, China

Application:

Kitchen Cabinet Doors Furnitures Making

Key Selling Points:

Easy To Operate,High-accuracy

Cabinet:

Furniture, Doors And Cabinets Industry

Working Voltage:

380/220V 50Hz

Packaging Details:

3310*2250*1030mm

Highlight:

CNC Router Machine Automatic

Wood Door Making CNC Router Machine

Automatic Wood Carving CNC Router

Product Description

Automatic Wood Door Machine Woodworking Carving Router 2140

The CNC milling and engraving machine BHM 2140 is a customized machine designed for cutting materials of impressive size. The all-welded machine bed provides the required level of rigidity and vibration resistance. The model is used for milling 3D cutting, engraving and cutting wood, MDF, chipboard, plexiglass, PVC, composite, and aluminum.

This is a cost-effective numerical control equipment, which can perform door panel carving, hollow carving, character carving, and cut various non-metallic plates including density board, acrylic, two-color board, and solid wood board.

Technical Specifications

Component	Specification
Fuselage structure	Square tube welded bed body, detachable
Longmen structure	Thickened square steel gantry, cast iron columns
Mesa structure	Aluminum profiles+PVC, vertical laying of profiles
Body size	500026001750mm
Table size	2100*4000mm
Effective work schedule	1.3mX2.5m (standard board size)
Machining accuracy	0.05mm
Transmission structure	Three axis 20 square track and slider
Rack	1.25m high-precision gear rack
Z-axis component	Drive belt+gear transmission
Motor set	Chuangwei 450B stepper motor
Driver	Skyworth 860 Drive
Spindle power	7.5KW air-cooled spindle, speed 25000 RPM
Frequency converter	Zhuzhou 9.5KW frequency converter
Operating system	JM Weihong
Cabinet	Independent chassis control cabinet
Machine color	Grayish green
Working voltage	380/220V 50Hz

Special reminder: Different customers can customize models and configurations according to their needs. Due to product variety, orders require prepayment. We provide quotations based on customer requirements. Please confirm actual pricing with our staff according to product model configuration.

Key Features

Aluminum profile with PVC countertop: Large aluminum profile surface provides stable load-bearing capacity, with PVC base protecting the aluminum profile.
Stepping motor: High-quality spindle and cutting head enable long operation time, reduced losses, fast bearing speed, and low noise.
Square steel gantry frame: 1cm thick heat-treated square steel gantry frame ensures good rigidity, smooth operation, and high machine accuracy.
Drag chain: New wear-resistant drag chain with separated signal and power lines prevents signal interference and eliminates cable distortion during operation.

Applications

1. Wood furniture industry

Doors; Cabinets; Tables; Chairs
Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards

2. Advertising industry

Signage; Logo; Badges; Display board; Meeting sign board; Billboard
Advertising field, sign making, acrylic engraving and cutting, crystal word making, blaster molding

3. Die industry

Sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, and other non-metallic mold

4. Artwork and Decoration

Wood crafts; gift box; jewelry box

5. Others

Relief sculpture and 3D engraving and Cylindrical object

Frequently Asked Questions

Q1: Can customized services be supported?

A1: Yes, we can customize the color, size and logo you need.

Q2: Where is your factory located?

A2: We are a Chinese manufacturer in Qingdao city, Shandong province.

Q3: Can you make the machine according to my design or prototype?

A3: Yes. We have professional designers to create the most suitable design and production plan for your requirements.

Q4: This is the first time I use this kind of machine, is it easy to operate?

A4: We provide guide videos and English instruction manuals with the machine. Our team offers free professional guidance until you can operate the machine proficiently.

Q5: What's your MOQ and delivery?

A5: Minimum order quantity is 1 set. We ship directly to your country's port - please provide your port name for the best shipping rates and machine pricing.

Q6: How is your after sales service?

A6: Our sales team is available 24/7. We also provide overseas installation services.

Q7: If my machine is broken, can you repair it for me?

A7: Yes. We offer free online training. For major issues during warranty period, we provide repair services.
